 "KAC-5001PS MONO PERFORMANCE AMP")
RATED OUTPUT
4 ohms 300W x 1
2 ohms 500W x 1
4 ohms 300W x 1
2 ohms 500W x 1
Signal to Noise Ratio: 100 dB
Low Pass Filter: 50 - 200 Hz (-24 dB / oct.)
Bass Boost: 40 Hz (0 - +18 dB)
Size(inch): (W)9-7/16" x (H)2-3/16" x (D)7-9/16"
Weight(lbs): 4.0
Power Output
300Watts RMS x 1 at 4 Ohms and 1%THD+N
MAX POWER 1000W
4 (2 to 8 allowable)
Bridged connection 4 to 8 allowable
300Watts RMS x 1 at 4 Ohms and 1%THD+N
MAX POWER 1000W
Rated Power at 14.4V
300Watts RMS x [ch] (4 Ohms, 20-200Hz, 1.0% THD)
500Watts RMS x [ch] (2 Ohms, 100Hz, 1.0% THD)
4 (2 to 8 allowable)
Bridged connection 4 to 8 allowable
Current Consumption 36 [A]
